| Specifikacije |
|---|
Description | High production colour and b&w wide format printing system | Type | Electrophotography (LED) with organic photoconductor (OPC) and closed toner system | Speed | Up to 390 sq. m per hour in b&w – 325 sq. m per hour in colour | Warm up time | Less than 6 minutes from power on | Configurations | Printer or multifunction system (print/copy/scan) | Toner | Four colour (CMYK), dry toner. Printed images are UV lightfast and waterproof | Electrical requirements | 220 – 240 V, 50/60 Hz, 20 A | Power consumption | Standby: 0.8 kW, Printing: 2.0 kW, Sleep Mode: 10 W | Dimensions | 1,376 mm (w) x 790 mm (d) x 1,450 mm (h) | Weight | 540 kg | Power consumption | 3.0 kWh (printing), 1.0 kWh (standby) | Acoustic noise | < 65 db (printing), < 55 db (standby) | Room temperature | 10 – 32°C | Print resolution | 600 x 2,400 dpi | Paper capacity | 418 sq. m 3 rolls + cut sheet bypass | Output sizes width (roll media) | 297 mm – 914 mm | Output sizes length (roll media) | 210 mm minimum, 39 m maximum | Paper weight (roll media) | Bond: 164 – 150 gsm, Vellum: 80 – 95 gsm, Film: 75 micron, Gloss: 120 gsm | Multi sheet bypass | Automatically feeds up to 50 sheets of 75 gsm bond / Maximum sheet size 420 mm x 594 mm / Minimum sheet size 420 mm x 297 mm | Single sheet bypass | Up to 120 gsm bond / Maximum sheet size 914 mm x 594 mm / Minimum sheet size 420 mm x 297 mm | Media types | Bond, translucent bond, film, double matte, double matte, clear film, weather proof banner film, waterproof bond, film white opaque adhesive back/6 mil, film clear adhesive back, Blue Back, bright fluorescent bond, (yellow, orange, green, blue), fusion banner media | Type | Embedded with Windows 7 CPU: Quad Core | Memory | 3 GB | Compatible file formats | Raster colour: TIFF, JPG, JPG2000, PNG, BMP, GIF, TGA, RLE/RLC Vector colour/b&w: HPGL, HPGL/2, HP-RTL, Postscript (PS/EPS), Adobe PDF, Autodesk DWF, Multipage PDF & DWF Raster b&w: TIFF Group 3 & 4, CALS Group 4, Grayscale TIFF, CIT/TG4 Vector b&w: Calcomp 906/907 | | KIP 940 Auto stacker | | KIP 2300 CCD scan system | | KIPFold 2000 |
- Podpora in razpoložljivost naštetih specifikacij in funkcionalnosti je odvisna od operacijskih sistemov, aplikacij, omrežnih protokolov, kot tudi omrežnih in sistemskih konfiguracij.
- Slike in ilustracije nekaterih produktov vsebujejo dodatno/opcijsko opremo.
- Opisi specifikacij in dodatne opreme so osnovani na osnovi trenutno dostopnih informacij in so lahko predmet sprememb brez predhodnega obvestila.
- Konica Minolta si pridružuje pravico do napak in ne garantira, da so vse informacije brez napak.
- Microsoft, Windows in Windows logo so blagovne znamke ali registrirane blagovne znamke Microsoft Corporation v ZDA in/ali drugih državah.
- Vsa ostala imena, znaki in logotip so lahko blagovne znamke ali registrirane blagovne znamke njihovih lastnikov in jih kot take priznavamo.
|
