| Specifikacije |
|---|
Description | Monochrome wide format print/copy/scan with colour scanner | Type | Electrophotography (LED) with organic photoconductor (OPC) and closed toner system | Speed A1 size per minute | 10 | Warm up time | Less than 2 minutes from standby | Configurations | Printer / MFP | Roll options | 2 or 4 Roll | Output delivery | Top / rear | Electrical requirements | 220V-240V +6% or -10%, 50/60Hz, 13A | Power consumption | 1,500 W (printing), 430 W (standby) | Print resolution | 600 x 2,400 dpi | Paper capacity | 2 or 4 roll | Output sizes width | 297 mm – 914 mm | Output sizes length | 6 m (standard), 150 m based on media validation | Paper weight | Bond-plain 64–90 gsm; vellum-translucent-tracing 80 gsm; film 75 gsm | Media types | Bond, vellum, film | Controller type | KIP System K Controller with Windows® 7 embedded | Memory | 2GB DDR3 standard - upgradable to 4 GB | Hard drive minimum | 320 GB - unlimited upgrade | Supported file type | DWF, PDF, PDF-A, HPGL 1/2, HP-RTL, Calcomp 906/907, CALS Group 4, TIFF Group 4, CIT/TG4, Grayscale TIFF, TIFF Packbits, PNG, JPEG | Scanner Type | C.C.D. with KIP Tru-Speed Technology and KIP RTT Technology | Scan Resolution | 600 x 600 dpi optical resolution | Scan Speed | Up to 18 m per minute (Mono) and up to 9 m per minute (Color) | Scan Formats | TIFF, Multipage TIFF, PDF, PDF-A, Multipage PDF, DWF, Multipage DWF, JPEG, CALS | Scan Destination | Local USB (Removable Media), Unlimited IPS Mailboxes (Local), Unlimited FTP, Unlimited SMB | Original Size | Width/Length Originals Up to 1,066 mm - 914 mm Scan width | Original Thickness | Up to 16 mm Automatic thickness detection | Original | Face Up/Face Down Both - Dual Original Feed Tables | Interface | USB 2.0, KIP Tru•Speed Technology (2.3GB per sec data transfer) | Dimensions | 1,399 mm W, 480 mm D, 310 mm H | Weight | 73 kg | Electrical | 100-240V AC 50/60 Hz | Power Consumption | <120 W |
- The support and availability of the listed specifications and functionalities varies depending on operating systems, applications, network protocols as well as network and system configurations.
- Some of the product illustrations contain optional accessories.
- Specifications and accessories are based on the information available at the time of printing and are subject to change without notice.
- Konica Minolta does not warrant that all specifications mentioned will be error-free.
- Microsoft, Windows and the Windows logo are trademarks, or registered trademarks, of Microsoft Corporation in the United States and/or other countries.
- All other brand and product names may be registered trademarks or trademarks of their respective holders and are hereby acknowledged.
|
